Description
Less weight. More Fun
Whether you’re riding trails, exploring dirt roads, or putting some zip in your daily commute, riding an E-bike doesn’t have to be complicated. The all-new Talon E+ range lets you do it all, combining the exhilarating sensation of pedal-assist power with light and agile off-road handling. And its integrated system makes it all so seamless, so simple to use, you can forget about the technology and just enjoy the ride.
Key Performance Factors
SyncDrive Sport 2
This frame is paired with a SyncDrive Sport 2 motor and removable EnergyPak 430 battery that’s neatly integrated into a slim down tube to help minimize weight. The updated design allows space for two water bottles or a battery range extender for longer rides. A 100mm suspension fork helps smooth out bumpy terrain, while confident off-road geometry gives it a stable ride quality.
RideControl Dash 2
A new RideControl Dash 2 handlebar-mounted controller makes it easy to power on the bike and adjust support levels while you ride. You can also use the RideControl App to custom-tune the motor output and optimize range capabilities.
Designed Lighter
The frameset is crafted with lightweight aluminum shaped with sleek lines and modern styling. It weighs just 21.7kg (size medium)—significantly lighter than most other bikes in its category.
Specifications
-
MotorGiant SyncDrive Sport 2, 75Nm PedalPlus 6-sensor technology
-
BatteryGiant EnergyPak Smart 430Wh, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production, Giant EnergyPak Plus 200 range extender compatible
-
ChargerGiant EnergyPak smart charger 4A
-
ControllerGiant RideControl Dash 2, Smart Assist automatic mode, 5 support levels
-
DisplayGiant RideControl Dash 2, high-angle visibility, full color LCD display
-
SizesS, M, L, XL
-
ColoursAsphalt Green, Electric Blue, Meteor Storm
-
FrameALUXX aluminum, Overdrive 1½ – 1⅛” head tube, integrated KSA40 kickstand mount
-
ForkSR Suntour XCM ATB DS coil 29″ 100mm travel 15×110 AH axle
-
Shockn/a
-
HandlebarGiant Connect TR Riser 31.8×690~750mm
-
StemGiant Contact
-
SeatpostGiant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium
-
SaddleGiant Ergo Trail ESG
-
PedalsAnti-slip Platform
-
ShiftersShimano Cues
-
Rear DerailleurShimano Cues 9-speed
-
BrakesShimano MT200, hydraulic disc, 180mm [F/R]
-
Brake LeversShimano MT-200
-
CassetteShimano Cues, 11-41T, 9-speed
-
ChainKMC eGlide NP/BK, e-bike optimized
-
CranksetForged allumin direct-mount chainring steel 36T, Forged alumium crank arms
-
Bottom Bracketn/a
-
RimsGiant GX03V alluminum
-
HubseTracker Boost alloy 6-bolt disc 15x110mm [F] 12x148mm [R]
-
SpokesStainless steel
-
TyresMaxxis Rekon 29×2.4″
Highlights
Featuring an all-new lightweight aluminum frame that blends modern hardtail design with our latest E-bike technologies, the new Talon E+ delivers confidence and fun on off-road terrain. A lower top tube offers greater stand-over height, and a 100mm suspension fork soaks up bumps, giving you smooth control on trails or bumpy bike paths. The SyncDrive Sport 2 motor helps you conquer climbs, and the removable EnergyPak 430 battery is integrated into a slim down tube. Updated controls include a handlebar-mounted RideControl Dash 2 to power on the bike and adjust support levels. The frame is compatible with a dropper seatpost and features integrated mounts for a rear carrier, fenders, a kickstand and two water bottle cages, giving you the option to add an EnergyPak Plus range extender.
Geometry
-
- S
- 163 cm
174 cm
-
- M
- 171 cm 182 cm
-
- L
- 179 cm 190 cm
-
- XL
- 187 cm 200 cm
| S | M | L | XL | ||
| A | Seat Tube Length (MM) | 385 | 435 | 485 | 535 |
| B | Seat Tube Angle | 78.0° | 74.0° | 74.0° | 74.0° |
| C | Top Tube Length (MM) | 580 | 600 | 620 | 640 |
| D | Head Tube Length (MM) | 100 | 115 | 130 | 145 |
| E | Head Tube Angle | 68.0° | 68.0° | 68.0° | 68.0° |
| F | Fork Rake (MM) | 46 | 46 | 46 | 46 |
| H | Wheelbase (MM) | 1144 | 1165 | 1187 | 1209 |
| I | Chain Stay Length (MM) | 470 | 470 | 470 | 470 |
| J | Bottom Bracket Drop (MM) | 60 | 60 | 60 | 60 |
| K | Stack (MM) | 613 | 627 | 641 | 655 |
| L | Reach (MM) | 404 | 420 | 436 | 452 |
| M | Stand Over Height (MM) | 723 | 753 | 788 | 808 |
| N | Handlebar Width (MM) | 750 | 750 | 780 | 780 |
| O | Stem Length (MM) | 50 | 50 | 50 | 50 |
| Q | Wheel Size | 29″ | 29″ | 29″ | 29″ |
