LIV Avail 2

Description

• Whether you’re seeking epic solo adventures or joining group road rides, the Avail is the perfect companion. Designed to be lightweight and comfortable, it provides the ultimate riding experience, empowering you to conquer your rides with ease and enjoy every moment on the road.

  Key Performance Factors

  Built for Endurance

  Lightweight and balanced, the modern endurance geometry delivers a smooth all-day ride experience.

  Power Transfer

  Equipped with OverDrive and PowerCore technologies, this efficient frameset offers superior stiffness without compromising compliance.

  Adaptable Comfort

  The Avail tackles the roads less traveled with larger-size tire compatibility and a D-Fuse seatpost to soak up road vibrations.

  Specifications

  • Sizes
    XXS, XS, S, M
  • Colours
    Matte Sandshell
  • Frame
    ALUXX-grade aluminium
  • Fork
    Advanced-grade composite, full-composite OverDrive steerer
  • Shock
    N/A
  • Handlebar
    Liv Connect, 31.8mm
  • Stem
    Liv Sport XXS: 80mm, XS: 80mm, S: 90mm, M: 100mm, L: 100mm
  • Seatpost
    Giant D-Fuse, alloy
  • Saddle
    Liv Approach
  • Pedals
    PEDALS NOT SUPPLIED
  • Shifters
    Shimano Claris 2×8
  • Front Derailleur
    Shimano Claris
  • Rear Derailleur
    Shimano Claris
  • Brakes
    Tektro TK-B177 calliper rim brake
  • Brake Levers
    Shimano Claris
  • Cassette
    Shimano CS-HG50, 8-speed, 11×34
  • Chain
    KMC XZ83
  • Crankset
    FSA Tempo, 34/50
  • Bottom Bracket
    cartridge
  • Rims
    Giant S-R3 Disc wheelset, 22mm inner width
  • Hubs
    Giant alloy
  • Spokes
    Stainless steel
  • Tyres
    Giant S-R3 AC, 700x28c
  • Extras
    28mm max tyre size

  All specifications listed are subject to change without notice.

  Sizing Guide and Geometry

  Sizing to be used as a reference only.

  • XXS

      145 cm  156 cm

  • XS

      153 cm  162 cm

  • S

      158 cm  169 cm

  • M

      165 cm  174 cm

  • L

      171 cm  182 cm



  		XXS	XS	S	M	L
  A	Seat Tube Length (MM)	395	430	465	500	535
  B	Seat Tube Angle	75.0°	75.0°	74.5°	74.0°	74.0°
  C	Top Tube Length (MM)	500	515	525	540	555
  D	Head Tube Length (MM)	120	135	150	170	190
  E	Head Tube Angle	70.0°	70.5°	72.0°	72.0°	72.0°
  F	Fork Rake (MM)	45	45	45	45	45
  G	Trail (MM)	76.2	73.0	63.5	63.5	63.5
  H	Wheelbase (MM)	986	998	990	1000	1016
  I	Chain Stay Length (MM)	420	420	420	420	420
  J	Bottom Bracket Drop (MM)	70	70	70	70	70
  K	Stack (MM)	514	530	550	569	588
  L	Reach (MM)	362	372	372	377	386
  M	Stand Over Height (MM)	662	687	716	744	772
  N	Handlebar Width (MM)	380	380	400	400	420
  O	Stem Length (MM)	70	70	80	90	90
  P	Crank Length (MM)	165	165	170	170	172
  Q	Wheel Size	700C	700C	700C	700C	700C
