Description
The Ghost Kato FS is built for riders who crave full suspension freedom. With a lightweight aluminium frame, efficient 4 bar rear suspension platform, it smooths out rough trails and powers through the climbs with ease. For control, comfort and fun on every ride – choose the Kato FS.
- Alloy Frame
- Suntour XCR34 Boost 2CR Fork
- Suntour Raidon R Rear Shock
- Shimano CUES 10 Speed Gears
- Tektro HD-M535 Hydraulic Disc Brakes
Bike Geometry
- Bottom bracket drop [mm]:
- · 21.6 mm
- · 36.2 mm
- Chain stay length [mm]:
- · 430 mm
- · 450 mm
- Head tube angle: 66 degrees
- Head tube length [mm]:
- · 110 mm
- · 120 mm
- · 135 mm
- · 160 mm
- Reach [mm]:
- · 415 mm
- · 451 mm
- · 463 mm
- · 494 mm
- · 521 mm
- Stack [mm]:
- · 587 mm
- · 625 mm
- · 639 mm
- · 662 mm
- Stand over height [mm]:
- · 698 mm
- · 700 mm
- · 715 mm
- · 726 mm
- · 744 mm
- Seat tube angle: 77 degrees
- Seat tube length [mm]:
- · 385 mm
- · 395 mm
- · 415 mm
- · 435 mm
- · 465 mm
- Top tube length [mm]:
- · 550 mm
- · 586 mm
- · 606 mm
- · 641 mm
- · 674 mm
- Wheelbase [mm]:
- · 1145 mm
- · 1181 mm
- · 1231 mm
- · 1268 mm
- · 1305 mm
Brake system
- Brake Front Mount: Post Mount
- Brake Rear Mount: Post Mount
- Brake Front Description: Tektro, Hydraulic Disc brake, HD-M275, 2 pistons, resin pad, 180 mm
- Brake Rear Description: Tektro, Hydraulic Disc brake, HD-M275, 2 pistons, resin pad, 180 mm
- Brake Lever Description: Tektro, HD-M535-BL
- Brake Rotor Description: Tektro, TR180-35 180 mm, Centerlock
Drivetrain
- Cassette Teeth: 11-48T
- Crank Arm length: 170
- Crankset Teeth: 32T
- Crankset Type: single
- Pedal Inclusive: Yes
- Bottom Bracket Description: Shimano, BSA, Deore SM-BB52 68/73 mm, HOLLOWTECH II
- Cassette Description: Shimano, CUES CS-LG300-10, HG
- Chain Description: Shimano, CN-LG500 9-11s, LINKGLIDE
- Crankset Description: Shimano, FC-MT512-1, 2-Piece Crankset
- Derailleur Hanger Description: Glory Wheel, UDH
- Derailleur Rear Description: Shimano, CUES RD-U6000 10/11s, Shadow+
- Gear Description: Shimano, Derailleur
- Pedal Description: XLC, Flat Pedal PD-M29 w/ Reflector + integrated Pins
- Shifter Right Description: Shimano, Triggershift, CUES SL-U6000-10R, Rapidfire+
Frame and more
- Framesize:
- · 39 cm
- · 40 cm
- · 42 cm
- · 44 cm
- · 47 cm
- Framesize Convection:
- · XS
- · S
- · M
- · L
- · XL
- Max loadable weight (KG): 120 kg
- Front Fork Type: Suspension
- Suspension Type: Fully
- Travel Front: 130 mm
- Travel Rear: 130 mm
- Front Fork Description: Suntour, XCR34-Boost AIR 2CR DS 15AH2-110 130 mm
- Frame Description: HIGH, Aluminium, Uni
- Shock Description: Suntour, Raidon R 210x50mm, Hardware: 30×8
Handlebar and Saddle
- Handlebar Diameter: 31.8 mm
- Handlebar Material: Aluminium
- Handlebar Width: 760 mm
- Seatpost Material: Aluminium
- Seatpost Travel (mm):
- · 125 mm
- · 150 mm
- Stem Length: 50 mm
- Handgrip Description: XLC, GR-S60 Sport Grip
- Handlebar Description: XLC, Flat bar, HB-M30, Dia. 31.8 mm, Backsweep: 9°
- Headset Description: Glory Wheel, Semi-integrated, Strummer Headset, 1SI11015Z ZS44/ZS56
- Saddle Description: XLC, SA-S10 143 mm Sport
- Seatpost Description: XLC, Dropperpost, Dropper SP-T21, Dia. 31.6 mm, Travel: 125 mm, 405 mm
- Stem Description: XLC, ST-M50, Dia. 31.8 mm, L: 50 mm, A-Head
Wheels and wheel components
- Hub Front Description: XLC, HF-M15 Boost 15×110 mm, 32H, Centerlock
- Hub Rear Description: XLC, HR-M15 Boost 12×148 mm, 32H, Centerlock, HG
- Rim Description: XLC, WR-M17 Disc 25/584 32H 6,5 mm Valve
- Rim Rear Description: XLC, WR-M17 Disc 25/584 32H 6,5 mm Valve
- Spoke Description: DT Swiss, ELEMENTAL 2.0
- Tyre Description: XLC, VT-M20 Summit, 57-584
- Tyre Rear Description: XLC, VT-M20 Summit
- Wheelsize Description: 27.5, 27.5
- Bottom bracket drop [mm]:
