Description
Bike Geometry
- Bottom bracket drop [mm]:
- · 45 mm
- · 60 mm
- Chain stay length [mm]:
- · 430 mm
- · 450 mm
- Fork offset [mm]: 300 mm
- Head tube angle: 68 degrees
- Head tube length [mm]:
- · 115 mm
- · 105 mm
- · 125 mm
- · 135 mm
- Reach [mm]:
- · 393 mm
- · 371 mm
- · 426 mm
- · 409 mm
- · 443 mm
- Stack [mm]:
- · 598 mm
- · 588 mm
- · 632 mm
- · 622 mm
- · 641 mm
- Stand over height [mm]:
- · 710 mm
- · 680 mm
- · 765 mm
- · 735 mm
- · 780 mm
- Seat tube angle: 73.5 degrees
- Seat tube length [mm]:
- · 400 mm
- · 360 mm
- · 480 mm
- · 440 mm
- · 520 mm
- Top tube length [mm]:
- · 570 mm
- · 545 mm
- · 615 mm
- · 595 mm
- · 635 mm
- Wheelbase [mm]:
- · 1089 mm
- · 1063 mm
- · 1154 mm
- · 1133 mm
- · 1175 mm
Brake system
- Brake Front Description: Tektro, Hydraulic Disc brake, HD-M280, 2 pistons, 180 mm
- Brake Front Mount: Post Mount
- Brake Rear Description: Tektro, Hydraulic Disc brake, HD-M280, 2 pistons, 180 mm
- Brake Rear Mount: Post Mount
- Brake Lever Description: Tektro, HD-M280-BL
- Brake Rotor Description: Tektro, TR180-35 180 mm, Centerlock
Drivetrain
- Bottom Bracket Description: Thun, BSA, PASO-ML 68-73
- Cassette Description: Shimano, Tourney CS-HG200-7, HG
- Cassette Teeth: 12-32T
- Chain Description: KMC, Z51 8s
- Crank Arm length: 170
- Crankset Description: Shimano, Tourney FC-TY301
- Crankset Teeth: 42-34-24T
- Crankset Type: triple
- Derailleur Front Description: Shimano, Tourney FD-TY600-L6 3×6/7s, Top Swing
- Derailleur Hanger Description: Ghost, GRH-21bl black + Screws FRHG0004
- Derailleur Rear Description: Shimano, Tourney RD-TY300-SGS 6/7s, Double Servo
- Gear Description: Shimano, Derailleur
- Number Of Gears: 21
- Pedal Description: XLC, Flat Pedal PD-M29 w/ Reflector + integrated Pins
- Pedal Inclusive: Yes
- Shifter Left Description: Shimano, Triggershift, SL-M315-L 3x7s, Rapidfire+
- Shifter Right Description: Shimano, Triggershift, SL-M315-7R, Rapidfire+
Frame and more
- Framesize:
- · 40 cm
- · 36 cm
- · 48 cm
- · 44 cm
- · 52 cm
- Framesize Convection:
- · S
- · XS
- · L
- · M
- · XL
- Max loadable weight (KG): 120 kg
- Front Fork Description: Suntour, SF18-XCE28 DS 9mm-Dropout, 1-1/8″ 100 mm
- Front Fork Type: Suspension
- Frame Description: HIGH, Aluminium, Uni
- Type kickstand mount: KSA40
- Suspension Type: Hardtail
- Travel Front: 100 mm
Handlebar and Saddle
- Handgrip Description: XLC, GR-S60 Sport Grip
- Handlebar Description: XLC, Riser Bar, HB-C32, Dia. 31.8 mm, Rise: 25 mm, backsweep 15°
- Handlebar Diameter: 31.8 mm
- Handlebar Material: Aluminium
- Handlebar Rise: 25
- Handlebar Width: 740 mm
- Headset Description: Glory Wheel, Semi-integrated, Strummer Headset, 1SI110 ZS44/ZS44
- Saddle Description: XLC, SA-S10 143 mm Sport
- Seatpost Description: XLC, Non Suspension, SP-R30, Dia. 31.6 mm, L: 350 mm, 350 mm
- Seatpost Material: Aluminium
- Stem Description: XLC, ST-M34, Dia. 31.8 mm, L: 50 mm, +/-7°, A-Head
- Stem Length: 50 mm
Wheels and wheel components
- Hub Front Description: XLC, HF-T20, QR 100 mm, 32H, Centerlock
- Hub Rear Description: XLC, HR-T10 QR 135 mm, 32H, Centerlock, HG
- Rim Description: XLC, WR-M17 Disc 25/584 32H 6,5 mm Valve
- Rim Rear Description: XLC, WR-M17 Disc 25/584 32H 6,5 mm Valve
- Spoke Description: DT Swiss, FACTORY 2.0
- Tyre Description: XLC, VT-M20 Summit, 57-584
- Tyre Rear Description: XLC, VT-M20 Summit
- Wheelsize Description: 27.5, 27.5
