Description
Technical Specification
-
- Year
- 2026
-
- Product Type
- e-MTB
-
- Category Name
- E-BIKE
-
- SubCategory Name
- SPORT
-
- Model
- T-Tronik X
-
- Frame
- Bianchi T-Tronik X, aluminium, 12×148 mm rear thru axle, Post mount 180 disc brake type, Front travel 120 mm, Internal cable routing in steerer, 800 Wh battery compatible sizes SM-MD-LG-XL
-
- Fork
- Suntour XCR34X, Air, 120 mm travel, Steerer tube 1,5″ tapered, 34 mm stanchions, 15×110 Boost axle, Rotor: minimum 180 mm, maximum 203 mm
-
- Headset
- Acros for internal cable routing
-
- Shifters
- Shimano Deore SL-M4100, Rapidfire Plus
-
- RearDerailleur
- Shimano Deore, RD-M4120, 10sp, Shadow design
-
- Crankset
- FSA CK-320/IS, Aluminium DieCast, Crank length: 170 mm
-
- BB
- Included in the drive unit
-
- Chain
- KMC e10S EPT, Anti-Rust
-
- Sprocket
- Sunrace CSMS2, 11-42T
-
- Brakes
- Shimano Deore BR-MT410, 2 piston, resin pad
-
- BrakeLevers
- Shimano Deore BL-MT401
-
- Wheels
- Velomann 622×30, 32 hole; Front hub: Shimano TC500 Thru axle; Rear hub: Shimano TC500 Thru axle
-
- Tire
- Obor Mike Bear, 29″x2,35″, 60 TPI
-
- Stem
- Velomann Viper0, alloy, Diameter 28.6 mm, Barbore 31,8 mm Size: 60 mm
-
- Handlebar
- Velomann Aluminium, Rise 15 mm, Barbore 31.8 mm, Width 740 mm
-
- Grips
- Herrmans Luna lock 130 mm
-
- Seatpost
- Velomann AL2014, Diameter: 31,6 mm, Seatback: 0 mm for size SM; Dropper, travel 125 mm for size MD-LG; Dropper, travel 150 mm for size XL
-
- SeatpostQR
- Ursus Alloy, Quick Release, Diameter 34,9 mm
-
- Saddle
- Velomann Velomann Gnd Full-fit Start Up, Carbon-steel rail, 262 mm x 145 mm
-
- Rotor
- Promax, Front: DT-203H, 203 mm, Rear: DT-180CLA, 180 mm
-
- Pedals
- FPD NW-91K, PP black body, Steel cage
-
- Motor
- Bosch Performance Line, 85 Nm
-
- Battery
- Bosch Powertube 600 Wh Horizontal
-
- Chargeur
- Bosch 4A
Size and frame geometry
| SIZE | A | B | C | D | E | F | G | G1 | X | Y | WB |
|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 400 | 591 | 470 | 55 | 100 | 724 | 74.5° | 66.5° | 415 | 634 | 1189 |
| M | 430 | 615 | 470 | 55 | 116 | 750 | 74.5° | 66.5° | 435 | 648 | 1215 |
| L | 480 | 638 | 470 | 55 | 131 | 776 | 74.5° | 66.5° | 455 | 661 | 1241 |
| XL | 520 | 662 | 470 | 55 | 146 | 802 | 74.5° | 66.5° | 475 | 675 | 1267 |
