Description
Exhilarating yet relaxing. With smooth, powerful pedaling assistance and comfortable handling, the new Expression E+ is a motivating companion for commuting, fitness riding, or just pedaling for the fun of it.
Key Performance Factors
Smart support
The new SyncDrive Core 50Nm motor has Smart Assist mode, which uses sensors to constantly determine and deliver the optimal level of support by automatically adjusting power output.
Comfort and control
A step-thru frame design with a 63mm suspension fork, suspension seatpost, powerful disc brakes and extra-wide 55mm tires combine for smooth confidence and control on a variety of road surfaces and conditions.
Full-Color Display
RideDash Evo (on select models) on the handlebar/stem area makes it easy to view ride data including speed, distance, battery level and navigation.
Specifications
-
MotorGiant SyncDrive Core, 50Nm, Powered by Yamaha, PedalPlus 6-sensor technology
-
BatteryGiant EnergyPak 600Wh, CO2 Neutral production
-
ChargerGiant EnergyPak 4A smart charger
-
ControllerGiant RideControl Dash, Smart Assist automatic mode, 5 manual support levels, USB-C (10W)
-
DisplayGiant RideControl Dash, high-angle visibility, full color LCD display
-
SizesS, M, L
-
ColoursGloss Cosmos Navy & Matte Copper Coin
-
FrameALUXX aluminium, monotube, Battery Semi Integrated, low step through design
-
ForkSR Suntour Mobie A32 DS Coil, 63mm travel 100x15mm axle
-
HandlebarAluminium, 30° back sweep, 31.8x660mm
-
StemAluminum angle adjustable stem
-
SeatpostSuspension 30.9x300mm
-
SaddleSelle Royal Essenza Plus
-
PedalsWellgo C097, PP/ Kraton body, Anti-slip
-
ShiftersShimano Nexus 7-speed RevoShift
-
BrakesShimano BR-MT200 hydraulic disc, 180mm [F], 160mm [R]
-
Brake LeversShimano BL-MT200
-
Cassette18T
-
ChainKMC Z1e HX, e-bike optimised
-
CranksetAluminium 38T
-
RimsGiant Double Wall Aluminium 622×21
-
HubsShimano HB-TC500-15 100×15 [F], Shimano Nexus 7 disc brake [R]
-
SpokesStainless 14G(2.0mm) [F]Stainless 13-14G(2.3-2.0mm) butted [R]
-
TyresSchwalbe Big Ben 55-622 Wire Bead w/ reflective stripe
-
ExtrasKSA18 direct mount kickstand
All specifications listed are subject to change without notice.
Highlights
This low-step through E-bike features the new Syncdrive Core2 55Nm, a compact and lightweight motor that’s ideal for commuters and recreational riders. It delivers 55Nm of torque and utilizes Smart Assist technology, which features six sensors including slope detection and an accelerometer to produce the precise amount of power needed at all times. The result is a quiet, natural ride experience. A suspension fork helps smooth out rough roads, and the RideControl Dash full-color display (on select models) makes it easy to keep track of battery level and support mode, along with cycling data like speed and distance.
Sizing Guide and Geometry
-
- S
- 158 cm
180 cm
-
- M
- 165 cm 187 cm
-
- L
- 172 cm 194 cm
| S | M | L | ||
| A | Seat Tube Length (MM) | 450 | 500 | 550 |
| B | Seat Tube Angle | 73.0° | 72.0° | 71.0° |
| C | Top Tube Length (MM) | 580 | 595 | 620 |
| D | Head Tube Length (MM) | 140 | 160 | 180 |
| E | Head Tube Angle | 70.0° | 70.0° | 70.0° |
| F | Fork Rake (MM) | 44 | 44 | 44 |
| G | Trail (MM) | 88.0 | 88.0 | 88.0 |
| H | Wheelbase (MM) | 1107 | 1111 | 1124 |
| I | Chain Stay Length (MM) | 470 | 470 | 470 |
| J | Bottom Bracket Drop (MM) | 60 | 60 | 60 |
| K | Stack (MM) | 622 | 641 | 659 |
| L | Reach (MM) | 390 | 387 | 393 |
| M | Stand Over Height (MM) | 515 | 515 | 515 |
| N | Handlebar Width (MM) | 690 | 690 | 690 |
| O | Stem Length (MM) | 90 | 90 | 110 |
| P | Crank Length (MM) | 170 | 170 | 170 |
| Q | Wheel Size | 700C | 700C | 700C |
