Description
The Raleigh Captus is back. With a completely new sleek frame platform, available in either low or midstep options. Lowstep featuring front suspension and a rack mounted battery, Midstep equipped with a downtube battery and a rigid alloy fork. Both options come with Shimano gears and brakes.
- All new 6061 alloy frame
- Bosch Active Line motor
- Bosch Purion 200 display
- 400Wh battery
- Shimano CUES 9 speed gearing
Specification
Brake system
- Brake Front Brand: Shimano
- Brake Front Kind: BR-MT200
- Brake Front Mount: Post Mount
- Brake Front Type: Hydraulic Disc brake
- Brake Rear Brand: Shimano
- Brake Rear Mount: Post Mount
- Brake Rear Type: Hydraulic Disc brake
Carrier
- Carrier Rear Brand: Raleigh
- Carrier Rear Kind: HD
- Carrier Rear Type: MIK
Drivetrain
- Cassette Brand: Shimano
- Cassette Kind: LG-300
- Cassette Teeth: 11-32
- Cassette Type: Cassette
- Chain Brand: Shimano
- Chain Guard Brand: SKS
- Chain Guard Kind: Chainbow
- Chain Guard Type: Chainguard
- Chain Kind: LG500
- Chain Type: Chain
- Crankset Brand: Samox
- Crankset Kind: 170mm BNI
- Crankset Teeth: 38
- Crankset Type: single
- Derailleur Rear Brand: Shimano
- Derailleur Rear Kind: RD-U4000
- Derailleur Rear Type: Cues
- Gear Brand: Shimano
- Gear Kind: CUES
- Gear Type: Derailleur
- Automatic Gear: No
- Shifter Right Brand: Shimano
- Shifter Right Kind: SL-U4000
- Shifter Right Type: Triggershift
E-bike components
- Battery Brand: Bosch
- Battery Capacity: 400 Wh
- Battery Location:
- · Downtube
- · Carrierpack
- Battery Removeable: Yes
- Charger Brand: Bosch
- Charger Type: Smart Charger
- Display Removeable: Not Removable
- Display Steercontrol: No
- Display Type: Led
- Max Support Speed [km/h]: 25 km/h
- Motor Brand: Bosch
- Motor Torque [nm]: 40 Nm
- Motor Location: Center
- Motor Type: Active Line
- Sensor: Pedalforce, speed & rotation
- Power Handle: No
- Walk Assist: Yes
Frame and more
- Framesize:
- · 48 cm
- · 53 cm
- · 57 cm
- · 41 cm
- · 46 cm
- · 51 cm
- Framesize Convection:
- · S
- · M
- · L
- · XS
- Front Fork Brand:
- · Raleigh
- · Suntour
- Front Fork Kind: SF20-NEX 50mm
- Front Fork Type:
- · Non Suspension
- · Suspension
- Stand Brand: Ursus
- Stand Kind: Mooi 40
- Stand Type: Single
Handlebar and Saddle
- Ring: Yes
- Handgrip Brand: Velo
- Handlebar Brand: Tranz X
- Handlebar Kind: 640mm
- Handlebar Material: Aluminium
- Handlebar Type: Trekking
- Headset Brand: VP
- Headset Kind: 1-1/8″ Caged Ball Bearings
- Headset Type: Threadless
- Saddle Brand: Selle Royal
- Saddle Kind: Wave
- Seatpost Brand: Kalloy
- Seatpost Kind: SP-DC1 350mm Length
- Seatpost Material: Aluminium
- Seatpost Type: Non Suspension
- Stem Adjustable: No
- Stem Brand: Tranz X
- Stem Kind: Ahead 70mm
- Steering Lock: No
Lighting
- Brake Light: No
- Front Light Brand: Herrmans
- Front Light Kind: MR-GO
- Front Light Type: Via E-bike System
- Rear Light Brand: AXA
- Rear Light Kind: Juno eBike 50mm 6-12V
- Rear Light Type: Via E-bike System
Other
- Connectivity App: Yes
- Suitable For Range Extender: No
- Suitable For Childseat: Yes
Wheels and wheel components
- Axle Type Front: Quick-release
- Axle Type Rear: Quick Release 5mm
- Hub Front Brand: Shimano
- Hub Front Kind: CUES HB-QC300 Centre-Lock
- Hub Rear Brand: Shimano
- Hub Rear Kind: CUES FH-QC300 Centre-Lock
- Mudguard Front Brand: EuroFender
- Mudguard Front Kind: Tempo 58mm
- Mudguard Rear Brand: EuroFender
- Mudguard Rear Kind: Tempo 58mm
- Rim Brand: Ryde
- Rim Kind: ZAC 421 Black 36 Hole
- Spoke Brand: Sapim
- Spoke Kind: Leader
- Tyre Brand: XLC
- Tyre Kind: Traverse
- Tyre Rear Type: Wired Tire
- Tyre Size Etrto: 50-622
- Wheel Size Rear: 28
